The Datalogic S300 is a heavy-duty photoelectric sensor in a 25 x 100 x 70 mm housing with terminal-block wiring. It is built for long distances, outdoor or dusty areas, and machines where a relay output or AC supply is needed, such as gates, cranes, timber, steel and bulk material handling.
S300 versions and ranges
| Model | Sensing mode | Range | Output | Supply |
|---|---|---|---|---|
| S300-PR-2-G00-EX + S300-PR-2-F01-OC | Through-beam (emitter + receiver) | 0 … 60 m | PNP/NPN open collector | 10 … 30 Vdc |
| S300-PR-1-B01-RX | Polarized retroreflective | 0.1 … 22 m | Relay SPDT, 3 A | 24…240 Vac / 24…60 Vdc |
| S300-PA-2-B01-OC | Polarized retroreflective | 0.1 … 10 m (R5) | PNP/NPN open collector | 12 … 30 Vdc |
| S300-PR-1-C01-RX | Diffuse proximity | 0.05 … 5 m | Relay SPDT, 3 A | 24…240 Vac / 24…60 Vdc |
| S300-PA-1-C06-RX | Diffuse proximity | 0.05 … 2 m | Relay SPDT, 3 A | 24…240 Vac / 24…60 Vdc |
All versions are IP67. The PR versions in glass-fibre reinforced PBT work from -40 to 55 °C.
Why choose a relay output?
A relay (RX) version can switch a contactor, lamp or small motor directly, with up to 3 A at 250 Vac. It also accepts a wide supply range, from 24 to 240 Vac or 24 to 60 Vdc. This makes it ideal for simple control panels without a PLC. The trade-off is speed: relay versions switch at about 25 Hz, while open-collector (OC) versions switch up to 500 Hz.
Typical applications
- Vehicle and gate detection at entrances and loading bays
- Long conveyors and overhead cranes
- Timber, steel and cement plants with dust and vibration
- Outdoor installations in cold or hot conditions
Installation tips
- For through-beam pairs, order both the emitter (EX) and the receiver (OC or RX).
- Align the beam at short range first, then move to the final distance.
- Use the sensitivity trimmer and the light/dark (D/L) setting to match the application.
