A safety light curtain creates an invisible field of infrared beams across a machine opening. When a hand or body part breaks the field, the curtain switches off its safety outputs and the machine stops. The Datalogic SG2 is a Type 2 safety light curtain for hand protection on machines with moderate risk.
SG2 key specifications
| Type | Type 2 safety light curtain, PL c (EN ISO 13849-1), SIL 1 |
|---|---|
| Resolution | 30 mm (hand protection) |
| Operating distance | 0.2 … 19 m |
| Safety outputs | 2 PNP (OSSD), 0.5 A max each |
| Response time | 8 … 24 ms, depending on height |
| Supply voltage | 24 Vdc ±20% |
| Housing | Painted aluminium, PMMA window |
| Protection | IP65 |
| Operating temperature | -10 … 55 °C |
Available protected heights
| Model | Protected height |
|---|---|
| SG2-30-015-OO-X | 150 mm |
| SG2-30-030-OO-X | 300 mm |
| SG2-30-045-OO-X | 450 mm |
| SG2-30-060-OO-X | 600 mm |
| SG2-30-075-OO-X | 750 mm |
| SG2-30-090-OO-X | 900 mm |
| SG2-30-105-OO-X | 1050 mm |
In the model code, 30 is the resolution in mm and the next three digits are the protected height in cm (015 = 150 mm).
Is Type 2 enough for my machine?
Type 2 (PL c, SIL 1) suits lower and medium risk machines. High-risk machines such as power presses usually need a Type 4 curtain. The required level comes from your machine’s risk assessment, so check it with your safety engineer before ordering.
Choosing the height and mounting
- Pick a protected height that covers the full opening an operator can reach through.
- Mount the curtain at the safety distance from the hazard. This distance depends on the machine stopping time and the curtain response time, as set out in EN ISO 13855.
- Make sure nobody can reach over, under or around the protected field.
- Connect both OSSD outputs to a suitable safety relay or safety PLC.
Applications
- Packaging and labelling machines
- Assembly stations and small automatic machines
- Access openings on conveyors and palletisers
